ALL IN ONE 10 kwh 7KWH 5kwh battery LiFePo4 Lithium Battery 48V 100Ah 150Ah 200Ah Deep Cycle UPS Solar Backup Energy Storage

2021-08-31 03:25

Specificatie
Model
AIN Battery
baterij type
LiFePO4
Battery Module
AIN4860
AIN48100
AIN48150
AIN48200
Battery capacity(Ah)
60
100
150
202
Nominal Battery Energy (kWh)
3
5.1
7.6
9.6
Max Output Power (kw)
2.4
4.8
7.2
10.3
Net Weight (Kg)
40
53
70
83
Dimension (H*W*D, mm)
700*580*210
Working Voltage (V)
43.2~58.4
Operating Temp. Range (℃)
-20~50
Calendar Life (Cycles)
Nominale spanning (V)
51.2
Beschermingsniveau
IP54
Communicatie
CAN / RS485
Garantie
10 Years
Certification & Safety Standard
TUV / CE / EN62619 / IEC62040 / UN38.3 / CEC geaccrediteerd
Monitoring & Protection
Each module have BMS , breaker embedded in system
HMI
LCD / touch screen

Kenmerken

◆ Gebruikmakend van de technologie van lithiumijzerfosfaatcel, superieure veiligheid, duizenden cycli, 100% DOD, onder normale omstandigheden.

◆ Ingebouwde automatische bescherming tegen overladen, ontladen, overstroom en te hoge temperatuur.
◆ Vrij van onderhoud.
◆ Balancering van interne cellen.
◆ Lichter gewicht: ongeveer 40% ~ 50% van het gewicht van een vergelijkbare loodzuuraccu.
◆ Opladen met de meeste standaard loodzuurladingen (set).
◆ Breder temperatuurbereik: -20 ℃ ~ 60 ℃.



Onze fabriek



Verpakking en verzending
FAQ

Q1: What products do you offer?

Our main products is Lithium Ion Batteries. Now we can offer Home EneBattery Pack,Lithium Battery 24V 48V energy Storage, Telecom Battery,  etc.
Q2: How can I get a sample to check your quality?
If you need sample to test, please pay for the freight and sample cost. And the sample cost will be returned back to you after you place an bulk order more than our MOQ.Q3: Can I have the products with my own logo?
Yes. We can offer both OEM and ODM service with prototype design and small MOQ.Q4: How long can I expect to get the sample?
The samples will be ready for delivery in 3~5days after we receive the payment.

Q5:Can you give me a discount?
Yes, based on wholesale service, we have better discount for bigger quantities. We will quote you the best price based on your order quantity.

Q6. What are the advantages that distinguish from others?
1. Official cooperative supplier of China State Grid Official
2. Withprofessional product development team
3. Rich experience in wireless computer room
4. With superior energy storage solution

Q7. How to do if I can’t reach your minimum order quantity?
Do not worry about that. If you can’t reach MOQ for each item, we suggest you refer to our goods in stock and group sourcing items. We also can send you the latest list of the prompt goods for your reference.



Notitie: Wij zijn een fabrikant van batterijen. Alle producten ondersteunen geen detailhandel, we doen alleen B2B-zaken. Neem contact met ons op voor productprijzen!
