Model | Uhome-LFP 5000 | Uhome-LFP 2400 | Uhome-LFP 2500 | Uhome-LFP 2600HV |
Totale energie (DC) | 5,1 kWh | 2,4 kWh | 2,5kWh | 2,56kWh |
Bruikbare energie (DC) | 4.6kWh | 2.2kWh | 2.2kWh | 2.2kWh |
Normaal ontlaad-/laadvermogen | 3.0kw | 2,75 kW | 3,75 kW | 4,6 kW |
Piekvermogen (alleen ontlading) | 6kw voor 3s | 3kw voor 3s | 3kw voor 3s | 3kw voor 3s |
Constante stroom (alleen ontlading) | 80A | 40A | 40A | 20A |
Spanning | 48-56Vdc | 48-56Vdc | 48-56Vdc | 96-112Vdc |
Normaal voltage | 51.2Vdc | 51.2Vdc | 51.2Vdc | 102.4Vdc |
Normale stroom | 60A | 30A | 30A | 15A |
Max.laadspanning: | 57,6Vdc | 57,6Vdc | 57,6Vdc | 115,2Vdc |
Gewicht | 45kg | 27,5 kg | 23kg | 24 kg |
Afmeting (mm) | 500*442*135mm | 500*442*133mm | 500*442*88mm | 500*442*88mm |
Max.aanbevolen DOD | 90% | |||
Bedrijfstoestand: | Binnen | |||
Bedrijfstemperatuur | 0--45 gr. (lading); -10-- 50 gr. (ontlading) | |||
WIFI-frequentiebereik | 2400MHz--2483MHz | |||
Vochtigheid | <60% (Geen gecondenseerd water) | |||
Vervuilingsgraad | 3 | |||
Overspanningscategorie | II | |||
Type koeling: | Natuurlijke koeling | |||
Case materiaal | Metaal | |||
Kleur | Zwart of wit | |||
Installatie | Wandmontage/grondinstallatie | |||
IP waarde | IP20 | |||
Beschermende klasse | l | |||
Max.aantallen parallel of serie | 8S/4P | 8S/8P | 8S/8P | 6S |
Garantie | 10 jaar | |||
Levensduur | >15 jaar | |||
Communicatie | KAN/RS485 | |||
Beschermingsmodus: | Dubbele hardwarebescherming | |||
Batterij bescherming | Overstroom/Overspanning/Kortsluiting/Onderspanning/Overtemperatuur | |||
Veiligheid | CE TUV | |||
Classificatie van gevaarlijke stoffen | 9 | |||
vervoer | UN38.3 |
The Uhome Energy Storage battery has following advantages
1. Montage vrij in serie of parallel: tot 8S8P (448V326.4kWh)






A: Ja, we verwelkomen de monsterbestelling om de kwaliteit te testen en te controleren.Q2. Hoe zit het met de doorlooptijd?
A:Sample needs 15-18 days, mass production time needs 25-30 days.Q3. Heeft u een MOQ-limiet voor de batterij?
A: Depends on different models.For the very regular models,the MOQ is LOW.
V4. Hoe verzendt u de goederen en hoe lang duurt het voordat ze aankomen?
A: We usually ship by TNT, UPS, FedEx.... It usually takes 3-5 days to arrive. Airline and sea shipping also optional.
V5. Hoe plaats ik een bestelling voor een batterij?
A: Firstly,pls let us know your requirements,such as the dimension,continuous&peak discharge current, application of the battery.
Secondly,pls let us know the purchasing quantity and when will your project start.We quote according to the details.
Thirdly customer confirms the price,sample and places deposit for formal order.
Ten vierde regelen we de productie.
Q6. Is it OK to print my logo on battery ?
A: Ja. Informeer ons formeel vóór onze productie en bevestig eerst het ontwerp op basis van onze steekproef.
Q7: Biedt u garantie voor de producten?
A: Ja, we bieden 12 maanden garantie op onze producten.
Q8: Hoe om te gaan met defecten?
A: Firstly, Our products are produced in strict quality control system and the defective rate will be less
than 0.2%.
Secondly, during the guarantee period, we will send new batteries with new order to replace the defective.
Thirdly,we will test the defective batteries and make 8D report.We will find out the reason and propose the
improvement measures for future production.
